SD & microSD Cards

SD & microSD Cards

Form Factors: SD and microSD

NAND Options: QLC, TLC, MLC, pSLC and SLC

Capacity Range: 128MB to 1TB

Sequential Read: Up to 175 MB/s

Operating Grades: Commercial, extended and industrial

AMPSD SD Card Specifications

Standard SD storage for industrial and embedded applications, with multiple NAND, capacity, speed-class and temperature-grade options.

SeriesAMPSD

InterfaceSD, SDHC and SDXC

Speed ClassC2, C4, C6 and C10

UHS Speed ClassNon-UHS-I, U1 and U3

Video Speed ClassV10 and V30

Application PerformanceA1 and A2

NAND OptionsTLC, MLC, pSLC and SLC

Capacity Range128MB to 512GB across listed NAND options

Sequential ReadUp to 100 MB/s

Sequential WriteUp to 95 MB/s

Operating GradesCommercial, extended and industrial

ReliabilityS.M.A.R.T., bit-error refresh, wear leveling and bad-block management

Review AMPSD capacity options

NAND	Capacity Range	Maximum Read	Maximum Write
TLC	2GB–512GB	Up to 100 MB/s	Up to 95 MB/s
MLC	4GB–512GB	Up to 100 MB/s	Up to 95 MB/s
pSLC	2GB–128GB	Up to 100 MB/s	Up to 95 MB/s
SLC	128MB–32GB	Up to 100 MB/s	Up to 95 MB/s

Maximum performance depends on capacity, NAND and host configuration. Confirm the required speed class and temperature grade for the exact part.

AMPMS microSD Card Specifications

Compact removable storage compliant with applicable SD Association specifications, supporting SD and SPI modes with capacities up to 1TB.

SeriesAMPMS

InterfacemicroSD, microSDHC and microSDXC

Bus ModesSD mode and SPI mode

Speed ClassC6 and C10

UHS Speed ClassNon-UHS-I, U1, U3 and UHS-II

Video Speed ClassV10 and V30

Application PerformanceA1 and A2

NAND OptionsQLC, TLC, MLC, pSLC and SLC

Capacity Range2GB to 1TB across listed NAND options

Sequential ReadUp to 175 MB/s

Sequential WriteUp to 150 MB/s

Operating GradesCommercial, extended and industrial

Review AMPMS capacity options

NAND	Capacity Range	Maximum Read	Maximum Write
QLC	128GB–1TB	Up to 175 MB/s	Up to 150 MB/s
TLC	16GB–512GB	Up to 175 MB/s	Up to 150 MB/s
MLC	4GB–128GB	Up to 175 MB/s	Up to 150 MB/s
pSLC	2GB–128GB	Up to 175 MB/s	Up to 150 MB/s
SLC	2GB–16GB	Up to 175 MB/s	Up to 150 MB/s

The listed maximums cover the family. Actual performance and supported speed classifications vary by NAND, capacity and host.

Encrypted SD and microSD Specifications

Security-focused removable storage with authentication, hidden-access and write-protection functions for qualifying SD and microSD configurations.

FormatsEncrypted SD and encrypted microSD

InterfaceSD, SDHC and SDXC

Speed ClassC10

UHS Speed ClassU1 and U3

Video Speed ClassV10 and V30

Security OptionsSD Key, Hidden Function and Write Protect

NAND OptionsTLC, MLC, pSLC and SLC

Capacity Range4GB to 512GB across listed NAND options

Sequential ReadUp to 90 MB/s

Sequential WriteUp to 70 MB/s

Operating GradesCommercial, extended and industrial

Review encrypted-card configurations

Capacity by NAND

NAND	Capacity Range	Maximum Read	Maximum Write
TLC	32GB–512GB	Up to 90 MB/s	Up to 70 MB/s
MLC	4GB–128GB	Up to 90 MB/s	Up to 70 MB/s
pSLC	4GB–128GB	Up to 90 MB/s	Up to 70 MB/s
SLC	4GB–8GB	Up to 90 MB/s	Up to 70 MB/s

Security functions

Function	Purpose
SD Key	Encrypts stored data and permits decryption through correct authentication.
Hidden Function	Restricts protected data so it can be read only after valid user authentication.
Write Protect	Keeps protected data read-only unless a verified user is authorized to modify it.

Security features and implementation details vary by configuration. Confirm host integration and authentication requirements with AMP.

Frequently Asked Questions

What is the difference between SD and microSD?

Both are removable flash-memory card formats, but microSD is physically smaller. The host must support the selected physical format, interface generation, capacity type and speed classification.

Which NAND options are available?

AMP lists QLC, TLC, MLC, pSLC and SLC options across the portfolio. The available NAND types and capacities differ between AMPSD, AMPMS and encrypted-card configurations.

What security features are available on encrypted cards?

Qualifying encrypted SD and microSD cards support SD Key authentication, a hidden-data function and verified-user write protection. Confirm the required host integration and feature implementation with AMP.

Are industrial-temperature cards available?

Yes. Commercial, extended and industrial options are listed across the portfolio. The exact operating range and grade must be confirmed for the selected series and part number.

What information should I provide with an SD or microSD inquiry?

Provide the required form factor, capacity, NAND type, speed class, UHS or video class, application-performance class, security requirements, operating temperature, host platform and estimated annual volume.

SD & microSD Product Inquiry

SD and microSD Storage for Industrial and Embedded Systems

SD and microSD Options Available from AMP

AMPSD SD Cards

AMPMS microSD Cards

Encrypted SD and microSD
