Industrial eMMC Embedded Storage
eMMC (embedded MultiMediaCard) is a small storage chip that combines flash memory and its controller in one package soldered directly onto a circuit board. Industrial eMMC is built for wider temperatures and longer availability than consumer parts. AMP Inc. eMMC 5.1 runs from 4GB to 512GB, including 16GB, 32GB, 64GB and 128GB industrial parts, and is backward compatible with eMMC 4.41, 4.5 and 5.0 designs.
Compare capacities by grade below, or send us your capacity, package and temperature requirements.
- Interface
- eMMC 5.1 (backward compatible with eMMC 4.41, 4.5 and 5.0)
- Package
- 153-ball BGA (100-ball by inquiry)
- Capacity
- 4GB to 512GB
- Temperature
- −25°C to 85°C, −40°C to 85°C or −40°C to 105°C
- NAND
- pSLC, 3D TLC, MLC by inquiry
Managed NAND for Embedded Platforms
AMP eMMC combines NAND flash, a controller and firmware in one eMMC 5.1 BGA package, so your host sees simple, managed storage without handling raw NAND. It is a compact, cost-effective choice for boot, operating-system and application storage in single-board computers, industrial controllers, vehicle systems and connected devices.
Capacities run from 4GB to 512GB in 153-ball BGA packages, with 100-ball BGA for pSLC and MLC by inquiry. pSLC and MLC options cover low-density, write-intensive designs, and 3D TLC covers higher capacities, with 64-layer and 112-layer NAND on industrial and automotive parts. Extended-temperature (−25°C to 85°C), industrial (−40°C to 85°C) and automotive-temperature (−40°C to 105°C) grades are available. eMMC 5.1 is backward compatible with eMMC 4.41, 4.5 and 5.0, so it can replace eMMC 5.0 parts in established platforms.
eMMC Key Features
Up to −40°C to 105°C
Extended, industrial and automotive-temperature grades for vehicles, outdoor enclosures and unheated equipment.
Compact BGA Packages
153-ball BGA packages solder directly to the board, saving space in small designs. 100-ball is available for pSLC and MLC.
pSLC & 3D TLC NAND
From 4GB pSLC for endurance to 512GB 3D TLC for capacity. MLC is available by inquiry.
Up to 320 MB/s Read
Faster boot and application loading, with a built-in controller that handles error correction and wear leveling.
Data Protection
Secure erase and write protection on every eMMC 5.1 part, plus firmware power-loss protection on selected 153-ball parts.
Lifecycle & Customization
eMMC 5.1 replacements for eMMC 5.0 designs, fixed bill of materials and availability planning for long-running programs.
Features and performance vary by product family and part number. Ask AMP for the specifications of a specific part.
eMMC Products
Extended, industrial and automotive-temperature eMMC 5.1 in 153-ball BGA packages.
eMMC Capacities by Grade
| Family | 3D TLC | pSLC | MLC (verify availability) | Package |
|---|---|---|---|---|
| Extended-temperature eMMC 5.1−25°C to 85°C | 16GB – 512GB | 4GB | 4GB – 8GB | 153-ball BGA |
| Industrial eMMC 5.1−40°C to 85°C | 32GB – 256GB | 4GB – 16GB | 8GB – 16GB | 153-ball BGA (100-ball for pSLC/MLC by inquiry) |
| Automotive eMMC 5.1−40°C to 105°C | 32GB – 256GB | 4GB – 16GB | 8GB – 16GB | 153-ball BGA (100-ball for pSLC/MLC by inquiry) |
100-ball BGA is available by inquiry in 4GB pSLC and 8GB to 16GB MLC, in industrial and automotive grades, for existing designs built around that footprint.
Need MLC? Contact us to verify availability for your design.
Need a capacity or package that isn’t listed? and AMP will recommend options.
Replacing an End-of-Life eMMC Part?
Capacity alone doesn’t make an eMMC part a drop-in replacement. AMP reviews your existing part, package, ball map and boot configuration and recommends options that fit electrically, mechanically and thermally, so requalification is as short as possible.
Send us what you have
The current part number, host board or system, capacity, temperature range and annual quantity.
We review compatibility
Interface, mechanical fit, NAND type, endurance, firmware features and security functions.
You get matched options
Recommended AMP part numbers to qualify, with lifecycle information to plan the rest of your program.
Applications
Automotive
Automotive-temperature (−40°C to 105°C) managed NAND for infotainment, telematics, digital cockpit and embedded vehicle systems.
View solutions
Transportation
Onboard computers, passenger information and fleet systems exposed to heat, cold and vibration.
View solutions
Military & Aerospace
Compact managed NAND for mission computing, avionics, unmanned platforms and rugged embedded systems.
View solutionsFrequently Asked Questions
What is eMMC?
eMMC (embedded MultiMediaCard) is managed NAND storage: flash memory, a controller and firmware in one BGA package that solders to the host board. The controller handles error correction and wear leveling, so the host works with it like a simple storage device.
Which eMMC versions and packages are available?
All current parts use the eMMC 5.1 interface. Extended-temperature parts come in a 153-ball BGA; industrial and automotive-temperature parts come in a 153-ball BGA, and pSLC and MLC parts are also available in a 100-ball BGA by inquiry. For eMMC 5.0 designs, AMP matches an eMMC 5.1 part in the same package.
What is the difference between eMMC 5.0 and eMMC 5.1?
eMMC 5.1 is the current version of the JEDEC standard. It adds features such as command queuing and is backward compatible with eMMC 4.41, 4.5 and 5.0, so an eMMC 5.1 part works in an eMMC 5.0 host using the features that host supports. AMP eMMC 5.1 is built for new designs and as the replacement path for existing eMMC 5.0 parts. If you are replacing an eMMC 5.0 part, so AMP can confirm the match.
Can eMMC 5.1 replace an eMMC 5.0 part?
Usually, yes. eMMC 5.1 is backward compatible with eMMC 4.41, 4.5 and 5.0, and with the same package and ball map it typically fits the existing board. Firmware, NAND type and boot configuration can differ, so plan a short qualification. and AMP will recommend a matching eMMC 5.1 part.
What capacities and NAND types are available?
Capacities range from 4GB to 512GB. pSLC covers 4GB to 16GB, MLC covers 4GB to 16GB, and 3D TLC covers 16GB to 512GB, depending on grade and product family.
Which NAND type should I choose?
Match it to how much your system writes. Write-heavy workloads such as data logging suit pSLC or MLC, while an operating system, applications and mostly-read data work well on 3D TLC.
Are industrial and automotive-temperature eMMC parts available?
Yes. Industrial parts are rated from −40°C to 85°C and automotive-temperature parts from −40°C to 105°C, in capacities up to 256GB. Extended-temperature parts are rated from −25°C to 85°C.
Is 64GB eMMC available in industrial temperature?
Yes. 64GB 3D TLC eMMC is available in industrial grade, rated −40°C to 85°C, and in automotive-temperature grade, rated −40°C to 105°C. Other common industrial capacities include 16GB, 32GB and 128GB.
Can I get part numbers for extended-temperature eMMC?
Yes. The extended-temperature eMMC 5.1 line (−25°C to 85°C) spans 4GB to 512GB, and part numbers are available on request. and AMP will send matching parts.
Is MLC eMMC still available?
For MLC, to verify availability for your design. AMP can also help you qualify a pSLC or 3D TLC alternative with similar endurance.
Can AMP help replace an end-of-life eMMC part?
Yes. Send the existing part number, package, host platform, capacity, temperature range and annual quantity, and AMP will recommend compatible options to qualify.
Need Help Selecting eMMC?
Tell us your capacity, package, temperature, NAND and lifecycle requirements and we’ll recommend matching eMMC part numbers.
